A flexible and user-friendly machine, derived from much experience in the field of transplanting. It has a high output without the need for frequent maintenance. Suitable for growers looking for performance without sacrificing flexibility. It is equipped with a single motorized head (40mm) and a plant detecting sensor . A 3-head Unit with pneumatic movement is also available. Both models feature the side pick-up system . Transplanting output: up to 3600 plugs/hour on DELTA1E version; up to 9000 plants/hour with the DELTA3 version. It can transplant from virtually any plug tray into almost any pot or pack configuration. Also suitable for transplanting into pots arranged in a line, fed from any model of potting machine. Source trays can be loaded lengthways or widthways through the machine to increase the transplanting options. Programming for different trays is simple and intuitive, performed by saving the tray dimensions into the computer memory. It has a large memory capacity for both pickup and placing programs. Saved setting can be recalled at the touch of a button. Operating speed, as well as pickup and deposit depths, can be adjusted while the machine is running. The display shows operational data as well as any errors or malfunctions. The DELTA1E version is fully electric and does not require a compressed air connection.

Main specifications

• Suitable for standalone use or in-line with other machinery • Models: with 1 electrical head or with 3 pneumatic heads • Maximun output: DELTA1E : 3600/plugs/hour - DELTA3 : 9000/plugs/hour • Switchable side-pickup option • Sensor to detect plants (on DELTA1E only) • Standard 40mm head • Machine dimensions: cm 150 x 300 x h 224 • Weight Kg. 600 • Voltage: 220V single-phase or 380V 3-phases+N • Air pressure (for DELTA3 only): 8 Bar
